The Motion Pro Vortex Throttle Assembly is a redesigned, compact throttle control built for improved performance, smooth operation, and efficient handlebar space use. This black-finished assembly features die-cast aluminum construction with a billet aluminum cover and includes the durable Motion Pro Titan Throttle Tube. It fits standard 7/8-inch, 22 mm handlebars and is designed to replace the OEM throttle on many Japanese two-stroke motocross motorcycles.
Feature: Smooth Operation: A POM pulley with a brass bearing provides a smooth throttle feel and increased wear resistance. Feature: Compact Design: The lighter, ultra-compact housing maximizes available handlebar space. Feature: Fast Twist Rate: The throttle opens at a rate of 0.526 mm of cable pull per degree of rotation and can open the carburetor to full throttle on most two-stroke motorcycles in approximately 70 degrees of rotation. Feature: Durable Construction: Die-cast aluminum housing, billet aluminum cover, and the included Motion Pro Titan Throttle Tube provide reliable service for demanding riding conditions.
The Motion Pro Vortex Throttle Assembly is compatible with Motion Pro DirtControl V2 and ODI V2 Lock-On grips when used with cam C. It fits Kawasaki KX125 and KX250 models from 1992 through 2005, Suzuki RM125 and RM250 models from 1995 through 2005, Yamaha YZ125 and YZ250 models from 1996 through 2010, and the 1997 Yamaha WR250Z using stock throttle cables. For Honda CR125 models from 1993 through 2003, Honda CR250 models from 1990 through 2004, and Honda CR500 models from 1990 through 2001, use Motion Pro Cable Part Number 70-1713. Additional special-application Motion Pro cables may be required for other motorcycle applications. Manufacturer and vendor part number: Motion Pro 01-1401.
Features:
- Completely redesigned Motion Pro Vortex throttle assembly with a lighter, ultra-compact housing
- Includes a durable Motion Pro Titan Throttle Tube
- POM pulley with brass bearing for smooth throttle operation and extended wear resistance
- Die-cast aluminum construction with billet aluminum cover
- Smooth black painted finish
- Fits standard 7/8-inch, 22 mm handlebars
- Compatible with Motion Pro DirtControl V2 and ODI V2 Lock-On grips using cam C
- Fits many Kawasaki, Suzuki, Yamaha, and Honda two-stroke motocross applications
- Uses stock throttle cables on listed Kawasaki, Suzuki, and Yamaha models
- Requires Motion Pro Cable Part Number 70-1713 for specified Honda CR125, CR250, and CR500 applications
- Fast twist rate provides 0.526 mm of cable pull per degree of rotation
- Opens the carburetor to full throttle on most two-stroke motorcycles in approximately 70 degrees of rotation
Fitment:
1990 Honda CR250R
1991 Honda CR250R
1992 Honda CR250R
1993 Honda CR125R
1993 Honda CR250R
1993 Honda CR500R
1994 Honda CR125R
1994 Honda CR250R
1994 Honda CR500R
1995 Honda CR125R
1995 Honda CR250R
1995 Honda CR500R
1996 Honda CR125R
1996 Honda CR250R
1996 Honda CR500R
1997 Honda CR125R
1997 Honda CR250R
1997 Honda CR500R
1998 Honda CR125R
1998 Honda CR250R
1998 Honda CR500R
1999 Honda CR125R
1999 Honda CR250R
1999 Honda CR500R
2000 Honda CR125R
2000 Honda CR250R
2000 Honda CR500R
2001 Honda CR125R
2001 Honda CR250R
2001 Honda CR500R
2002 Honda CR125R
2002 Honda CR250R
2003 Honda CR125R
2003 Honda CR250R
2004 Honda CR250R
2005 Honda CR250R
2006 Honda CR250R
2007 Honda CR250R
