The Alpinestars Supertech R10 Helmet in Team Matte Black/Carbon Red Fluo/Blue is a premium race-focused helmet engineered for advanced protection, aerodynamic stability, and rider comfort. This 2XL helmet features a multi-composite outer shell made from a 3K high-density carbon outer layer, uni-directional carbon composite, aramid fiber, and fiberglass. The pre-preg fiber construction uses epoxy resin to optimize the balance of resin and fiber, helping deliver strong mechanical performance, efficient energy dissipation, and controlled shell deflection during an impact.
The Supertech R10 uses four inner shell configurations and an eight-piece, multi-density EPS liner with six strategically positioned densities. This construction is designed to provide a close, comfortable fit while managing impact energy across multiple zones. A smooth, low-friction EPS surface helps address linear and oblique forces by allowing the comfort liner and rider’s head to move more independently inside the helmet. The A-Head Fitment System allows the helmet’s height and angle to be adjusted for a personalized setup, helping optimize both comfort and protective performance.
Developed through CFD simulations and validated in wind tunnel and track testing, the Alpinestars Supertech R10 is shaped for low drag and aerodynamic stability. It includes standard and longer race spoilers with elastic joints designed to detach during a significant impact, along with lateral winglets that support stability. Visor turbulators help improve aero-acoustic performance. The helmet also includes 11 ventilation points, with dedicated intake and exhaust ports connected to internal EPS air channels for effective airflow management. A large top slider directs air toward the crown and helps extract heat, while rear exhaust vents discharge hot air.
The chin bar vents are positioned beside the shield lock mechanism and can be opened or closed using integrated tabs. Their airflow is directed along the inside of the shield to help reduce fogging and misting, while separate chin bar exhausts help remove humid air. Finished in the Team Matte Black/Carbon Red Fluo/Blue colorway, this Alpinestars helmet combines race-developed aerodynamics, advanced impact management, adjustable fit, and targeted ventilation in a high-performance design. Part number 8200224-1383-XXL identifies this 2XL configuration.
Features:
- Outer Shell: Multi-composite construction combines 3K high-density carbon, uni-directional carbon composite, aramid fiber, and fiberglass for strength, energy management, and controlled shell deflection.
- EPS Liner: Eight-piece, multi-density EPS liner uses six specific densities positioned throughout the helmet for targeted impact absorption and a comfortable fit.
- Oblique Impact Management: Smooth, low-friction EPS surfaces help reduce rotational and oblique forces by allowing controlled movement between the comfort liner and EPS.
- A-Head Fitment System: Adjusts helmet height and tilt angle to help create a personalized fit and optimized protective position.
- Aerodynamics: CFD-developed and wind-tunnel-validated design supports low drag and aerodynamic stability at speed.
- Spoilers: Includes standard and longer race spoilers with elastic joints designed to detach during a significant impact.
- Ventilation: Eleven ventilation points, internal air channels, and dedicated intake and exhaust ports promote airflow and heat extraction.
- Anti-Fog Airflow: Chin vents direct air along the shield to help reduce fogging and misting.
- Configuration: Team Matte Black/Carbon Red Fluo/Blue finish in 2XL sizing.
- Part Number: 8200224-1383-XXL.
